8 100M RJ45 Ports IEEE802.3ab POE Switch Support Management

Product Categories

HiOSO Technology Co., Ltd.

Contact Now

Name: 8 100M RJ45 Ports IEEE8023ab POE Switch Support Management
Brand: Hioso
Price: 1 USD

Brand Name : Hioso

Model Number : FOWAY1309PFCM

Certification : CE, RoHS, CCC

Place of Origin : China, Guang dong

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 2000pcs/month

Delivery Time : 3-10 working days

Packaging Details : 38X24X18 CM

Item : Poe Switch

Poe : 8 poe ports

Port : 1 Combo port

Support : IP camera

MAC : 8K

Storage : 1M

Contact Now

9 Ports Ethernet Poe Switch 8 100M POE + 11000M Combo Port Support Management

Character

Support Maximum 8 100M PoE ports and 1 1000M Combo port (100M/1000M SFP port and 10/100/1000M RJ45 port optional)
Each PoE port supports to auto discovery the standard power receiving devices
Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
Support each port full rate, full-duplex non-blocking forwarding
Support 8K MAC learning, 1Mbit storage and forward cache space, 4.6G back plane bandwidth
Each RJ45 port using anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
Support to provide wall-mounted hanger better for installation if need, metal casing better for heat dissipating

Technical Specification

Parameter	Specification
Standard	IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet, IEEE802.3af, IEEE802.3at, IEEE802.1d Spanning Tree
PoE	Power supply ports: 8 ports Standard and power consumption: IEEE802.3af 15.4W, IEEE802.3at 30W Working mode: auto discovery power receiving devices and auto power supply/ cutting
Wavelength	SFP modules: 850nm/1310nm/1490nm/1550nm
Distance	100M SFP multi-mode: 2Km Single-mode: 20/40/60/80/100/120Km Single-fiber single-mode: 25/40/60/80/100/120Km 1000M SFP multi-mode: 220m (fiber 62.5/125μm)/ 550m (fiber 50/125μm) Single-mode:10/20/40/60/80/100/120Km Single-fiber single-mode: 10/20/40/60/80/100/120Km Cat5:100m
Port	8 100M RJ45 ports (PoE optional): 10/100Mbps 1 1000M Combo port: 1 Gbps, 100M/1000M SFP&10/100/1000M RJ45
MAC	8K
Buffer memory space	1Mbit
Bit error rate	<1/1000000000
MTBF	100000 hours
Power	DC48V(External power), AC110V/220V & DC48V redundant power back up(Internal power)
Power consumption	10W
Working temperature	-10~60℃
Storage temperature	-40~80℃
Humidity	5%~90% non-condensing
Dimension	28mm (H)×193mm(W)×119mm (D)

8 100M RJ45 Ports IEEE802.3ab POE Switch Support Management
